Being ultra-light and slim, the UHM LED display weights 0.5 kg per unit with the minimum thickness of 1.5cm, allowing you to save the cost in shipping, installation, and maintenance
Pixel Pitch: 1.25mm/ 1.579mm/ 1.667mm/ 1.875mm/ 1.904mm/ 2mm
Get A QuotationWe adopt high-effect power supply, lower output power, and reduce the heat generated by the power supply.
As the metal structure of our LED display has good thermal conductivity, it could cool off quickly to have a good performance, so as to sustain the 7X 24 hours' service routine.
A fast radiating structure without spans allows our LED display makes no noise in the working while being energy-saving.
To save your cost of shipping and installation, better materials are used to make thinner and lighter products which allow you to load more display screens in the container and install more quickly.
As our UHM LED display is specially designed for indoor using, it only weighs 2.5kg per unit with a maximum thickness less than 4cm and a minimum thickness of 1.5cm.
To make it convenient for distributor and contactor to make big purchases to lower the costing, we promote a series of UHM LED display screen of superior compatibility.
By doing so, you can employ 6 types of screens freely for the same platform as they can splice together seamlessly.
| Technical Specifications | P1.25 | P1.579 | P1.667 | P1.875 | P1.904 | P2 |
| Pixel Pitch | 1.25mm | 1.579mm | 1.667mm | 1.875mm | 1.904mm | 2mm |
| Pixel Configuration | SMD1010 | SMD1010 | SMD1010 | SMD1515 | SMD 1515 | SMD1515 |
| Module Size | 320*160mm | 240*240mm | 320*160mm | 240*240mm | 320*160mm | 256*128mm |
| Module Resolution | 256*128dots | 152*152dots | 192*96dots | 128*128dots | 168*84dots | 128*64dots |
| Pixel Resolution | 640,000dots/m2 | 401,111dots/m2 | 360,000dots/m2 | 284,444dots/m2 | 275,625dots/m2 | 250,000dots/m2 |
| Cabinet Size | 640*480*85mm | 480*480*85mm | 640*480*85mm | 480*480*85mm | 640*480*85mm | 512*512*85mm |
| Cabinet Weight | 9.2kg | 8.0kg | 9.2kg | 8.0kg | 9.2kg | 8.5kg |
| Average Comfortable Viewing Distance | 1.25m | 2.72m | 2.87m | 3.23m | 3.27m | 3.44m |
| Brightness | 600-800cd/m2 | 600-800cd/m2 | 600-800cd/m2 | 600-800cd/m2 | 600-800cd/m2 | 600-800cd/m2 |
| View Angle | 160°(W) 120°(H) | 160°(W) 120°(H) | 160°(W) 120°(H) | 160°(W) 120°(H) | 160°(W) 120°(H) | 160°(W) 120°(H) |
| Refresh Rate | ≥3，840HZ | ≥3，600HZ | ≥3，840HZ | ≥3，840HZ | ≥3，840HZ | ≥3，840HZ |
| Input Voltage | AC110v-220V±10% | AC110v-220V±10% | AC110v-220V±10% | AC110v-220V±10% | AC110v-220V±10% | AC110v-220V±10% |
| Max.power Consumption | ≤650W/m² | ≤720W/m² | ≤690W/m² | ≤600W/m² | ≤600W/m² | ≤700W/m² |
| Avg. Power Consumption | 240W/m² | 240W/m² | 230W/m² | 200W/m² | 200W/m² | 280W/m² |
| Working Temperature | -20°C~+50°C | -20°C~+50°C | -20°C~+50°C | -20°C~+50°C | -20°C~+50°C | -20°C~+50°C |
| Storage Temperature | -30°C~+60°C | -30°C~+60°C | -30°C~+60°C | -30°C~+60°C | -30°C~+60°C | -30°C~+60°C |
| Working Humidity | 10%-95% | 10%-95% | 10%-95% | 10%-95% | 10%-95% | 10%-95% |
| Lifespan | 100,000hours | 100,000hours | 100,000hours | 100,000hours | 100,000hours | 100,000hours |
| Maintenance Mode | Front/Rear | Front/Rear | Front/Rear | Front/Rear | Front/Rear | Front/Rear |
